Module based on a single ATtiny85-microcontroller. Features: Gate signal for when the envelope is active Rising edge trigger output Decay/release length Digital envelope output SOURCECODE

This is a clock multiplier made for musical purpose, such as synthesizer/modular-systems or other things that would send out or receive 5v pulses. The current code is written for a ATTiny85, but should work fine on any Arduino etc. The program measures the time between each pulse input, and outputs a repeating pulse with an […]

This is a sequencer made for controlling modular systems. It has 8 knobs controlling the time/length of each step and 8 knobs controlling the CV output for each step, generating interesting rhythmic patterns. The sequencer has a random mode, start/stop, two time-multipliers and a slide switch. The sequencer is based on a teensy 2.0 source […]

This is a modular synthesizer build with focus on noise music or non-musical purpose. Using different effects, filters distortion etc. weird noise can be generated through feedback loops or external input. Overview If you have any questions about the schematics or other things, please feel free to contact me at contact@simonjuhl.net

This is a drone machine consisting of four identical oscillators. Each oscillator can be tuned by two potentiometer; course and fine. A patch-bay on the instrument are used to cross modulate the different oscillators, through frequency divisions. The machine also have a tone-control and volume control for controlling the output. Schematics The drone machine is […]

This is a modular video synthesizer, based of a VGA testing module. The Testing module breaks out into each color channel, horizontal and vertical -video sync. The picture coming from the tester can be changed using a gate signal trough an external mini jack. View this post on Instagram A post shared by @simonjuhl_ on […]

Conductive Touch synthesizer

This is a homemade synth/drone is based on 4 tiny electric motors, each with 0-5v CV. An internal piezo amplifies the vibrations from the motors so the sound can be plugged into a mixer etc. Schematics Here are some more build pictures on instagram: Link Each motor is driven by an NPN-transistor in this case: 2N2222. […]
